The Tanto 5120 eight-up plus imagesetter from Dainippon Screen images at high speeds with the superlative quality delivered by Screen’s acclaimed external drum and optical system engineering.
Its imaging speed is overwhelmingly fast. And its advanced external drum design assures the very highest quality and consistency. The Tanto 5120 features an efficient, highly-reliable, media handling system and a fast data interface which support rapid throughput. Media up to 838 x 1,145 mm (33” x 45”) can be imaged. In short, it delivers a powerful combination of specifications.
The Tanto 5120 is not only a high-speed, highly accurate imagesetter, it is also loaded with advanced features for greater productivity and ease of operation. The Tanto 5120 can output onto six different sizes of film at any of six optical resolutions, from 1,200 dpi to 4,000 dpi. Multiple internal punch-block and high-speed RIP options are available. The large-display, touch-screen graphic user interface enhances ease of operation.
Because superior quality, faster throughput, and greater versatility can be decisive in today’s competitive marketplace, Screen’s Tanto 5120 imagesetter is a critical component of a modern prepress workflow.
| Model name |
Tanto 5120 (DT-R 5120) |
| Exposure system |
External drum |
| Light source |
120 channel, high-power LED array (660 nm) |
| Resolutions |
1,200, 2,000, 2,400, 3,000, 3,500*, 4,000 dpi |
| Repeatability |
5 microns (0.2 mil) |
| Spot size |
Variable: 6.35 microns at 4,000 dpi; 21.17 microns at 1,200 dpi |
| Exposure speed |
Up to 11,948 sq.cm/min. (1,852 sq.in./min.) at 1,200 dpi |
| Drum speed |
270 or 420 rpm |
| Compatible RIPs |
AD-510PM; HQ-510PM and PC ; T-RIP 600, Trueflow |
| RIP interface |
F-PIF |
| Weight |
Basic: 490 kg (1,078 lbs.) Fully equipped: 520 kg (1,144 lbs.) |
| Environment |
Operating: 18-28 C (64.4-82.4 F), 50-70%RH
Down time: 15-33 C(59.0-91.4 F), 30-80%RH
Storage: 10-40 C (50-104 F), 10-80%RH
|
| Power requirements |
Single phase 200-230 V 0.9 kW (including blower) |
|
|
Tanto DT-R 5120 OLP Imagesetter Images
|
